Heatit Z-Wave Thermostat, electronic thermostat for floor heating, White

Z-TRM3-W
Hover on image to enlarge
In stock
EGP3,460.00
White
Price in points: 173000 points
+

Heatit Z-TRM3 is an electronic thermostat for electrical floor heating, designed to be mounted in a standard flush box. The thermostat has a built-in Z-Wave chip that can be connected with Home Automation systems. Heatit Z-TRM3 is equipped with a single-pole switch and fits into System 55 frames. The thermostat can withstand a load of max 16A /3600W at 230V. The thermostat may be used for water based heating if the thermostat is linked to the Heatit Z-Water.

Our advantages
  • — 12 months warranty
  • — 14 Days Return
  • — Different payment methods
  • — Prices are VAT Inclusive
Payment options
Color Package
=
Total list priceEGP3,860.00
Price for allEGP3,780.00

Description

Specifications

Protocol Z-Wave – 868,4MHz
Chip Z-Wave 500 chip
Rated voltage 230V 50/60Hz
Max load 3600W (resistive load) 750W self-limiting heating cable
Max current 16A
Power consumption <2,0W
Ambient temperature 0°C to 40°C (during operation)
Temperature range 5°C to 40°C
Hysteresis 0,3°C to 3,0°C (default 0,5°C)
Compatible with NTC sensors with values 10, 12, 15, 22, 33 and 47 kΩ @ 25°C
IP Code IP 21
Approvals Z-Wave Plus, CE, EN 60730-1, EN 60730-2-9, EMC 2014/30/EU, RoHS 2011/65/EU, LVD 2014/35/EU

Features

Color:
White
Connection Technology:
Z-Wave

Downloads

Quick Guide (quickguide_heatit_z-trm3_ver2020-a_eng.pdf, 708 Kb) [Download]

Installation Manual (manual_heatit_z-trm3_fw_4.0_ver2020-b_eng.pdf, 863 Kb) [Download]

Package Contents

- 1 Thermostat.

- 1 Floor sensor.

- 1 3 meters  NTC 10 kΩ.
